The product offers either front access or rear access, allowing customers to choose installation options according to their environment and minimizes limitations in installation and maintenance.
The fast lock helps LED modules be simply set up or dismantled. Separate power and control unit design also facilitates easy maintenance.
| Category | Specification |
|---|---|
| Physical Parameter | |
| Pixel Configuration | 3 in 1 SMD |
| Pixel Pitch (mm) | 6.66 |
| Module Resolution (W x H) | 48 × 36 |
| Module Dimensions (W x H, mm) | 320 × 240 |
| Weight per Module (kg) | 1.30 |
| No. of Modules per Cabinet (W × H) | 2 × 3 |
| Cabinet Resolution (W x H) | 96 × 108 |
| Cabinet Dimensions (W × H × D) | 640 × 720 × 112.9 |
| Cabinet Surface Area (m²) | 0.461 |
| Weight per Cabinet (kg/cabinet) | 17.0 |
| Weight per Square Meter (kg/m²) | 36.9 |
| Physical Pixel Density (pixels/m²) | 22,500 |
| Flatness of Cabinet | ±0.5 mm |
| Cabinet Material | Die Casting Aluminum |
| Service Access | Front or Rear (One Option Only) |
| Optical Parameter | |
| Min. Brightness (After Calibration) | 5,000 |
| Color Temperature | 3,500 ~ 9,000 K |
| Visual Viewing Angle (Horizontal/Vertical) | 160 / 120 |
| Brightness Uniformity | 97% |
| Color Uniformity | ± 0.003 Cx, Cy |
| Contrast Ratio | 5,000 |
| Processing Depth (bit) | 14 |
| Electrical Parameter | |
| Power Consumption (W/cabinet, Max.) | 330 |
| Power Consumption (W/cabinet, Avg.) | 110 |
| Power Consumption (W/m², Max.) | 720 |
| Power Consumption (BTU/h/cabinet, Max.) | 1,126 |
| Power Consumption (BTU/h/cabinet, Avg.) | 375 |
| Power Consumption (BTU/h/m², Max.) | 2,457 |
| Power Supply (V) | 100 to 240 |
| Frame Rate (Hz) | 50 / 60 |
| Refresh Rate (Hz) | 3,840 |
| Operation Conditions | |
| Lifetime (Hours to Half Brightness) | 100,000 |
| Operating Temperature (°C) | -20℃ to +50℃ |
| Operating Humidity | 10-99%RH |
| IP rating Front / Rear | IP65 / IP65 |
| Certification | |
| Certification | CE, FCC, ETL |
| Environment | |
| Environment | RoHS |
| Controller | |
| Controller | LCIN006 |
