| Category | Specification | Details |
|---|---|---|
| Physical Parameters | Pixel Configuration | 3 in 1 |
| Pixel Pitch (mm) | 2.50 | |
| Module Resolution (W x H) | 100×100 | |
| Module Dimensions | Not Specified | |
| Optical Parameters | Min. Brightness (After Calibration) | 1,000 nits |
| Color Temperature | 3,000 – 10,000 K | |
| Visual Viewing Angle (H×V) | 160° × 140° | |
| Electrical Parameters | Power Consumption (W/cabinet, Max.) | 160 |
| Power Consumption (W/cabinet, Avg.) | 58 | |
| Power Consumption (W/m², Max.) | 640 | |
| Power Consumption (BTU/h/cabinet, Max.) | 546 | |
| Power Consumption (BTU/h/cabinet, Avg.) | 198 | |
| Power Consumption (BTU/h/m², Max.) | 2,184 | |
| Power Supply (V) | 100 to 240 | |
| Frame Rate (Hz) | 50 / 60 | |
| Refresh Rate (Hz) | 3,840 | |
| Operation Conditions | Lifetime (Hours to Half Brightness) | 100,000 hours |
| Operating Temperature (°C) | -10° to +40° | |
| Operating Humidity | 10-80% RH | |
| IP Rating Front | Not Specified | |
| Controller | Controller | LCLG006 |
| Certification | Certification | CE, FCC, cTUVus, CB |
| Environment | Environment | RoHS, REACH |
