Equipped with over 8 million self-lighting pixels operating individually, LG OLED Signage reproduces absolute blacks with no light bleed and offers infinite contrast.
LG OLED Signage delivers its awe-inspiring picture quality and brightness even from wide viewing angles.
The LAN daisy chain allows users to control and monitor displays, transmit data and even update firmware all at once, reducing management burden.
| Category | Specifications |
|---|---|
| PANEL | |
| Screen Size | 55″ |
| Panel Technology | OLED |
| Aspect Ratio | 16:9 |
| Native Resolution | 1,920 x 1,080 (FHD) |
| Brightness (APL25%, Typ.) | 400 cd/m² |
| Brightness (APL100%, Typ.) | 150 cd/m² |
| Contrast Ratio | 150,000:1 |
| Viewing Angle (H x V) | 178 x 178 |
| Life Time (Typ.) | 30,000 hrs |
| Operation Hours | 18 hrs/day, 7 days/week (Moving Video Only) |
| Orientation | Landscape & Portrait |
| CONNECTIVITY | |
| Input | HDMI, DP, USB 2.0 (2) |
| Output | DP, Audio (Fixed/Off/Variable) |
| External Control | RS232C In/out, RJ45 In/out, IR In |
| PHYSICAL SPECIFICATION | |
| Bezel Width (Off Bezel) | 0.6 / 0.6 / 6.7 / 6.7 mm |
| Bezel Width (On Bezel) | 5.0 / 5.0 / 7.8 / 13.2 mm |
| Monitor Dimension (Head, w/Pem-nut) | 701.4 x 1,219.7 x 38.0 mm |
| Monitor Dimension (Head Only) | 701.4 x 1,219.7 x 12.4 mm |
| Signage Box Dimensions | 413 x 353 x 57.3 mm |
| Weight (Head) | 7.8 kg |
| Weight (Signage Box) | 3.5 kg |
| Carton Dimensions | 1,350 x 837 x 250 mm |
| Packed Weight | 18.9 kg |
| ENVIRONMENT CONDITIONS | |
| Operation Temperature | 0°C to 40°C |
| Operation Humidity | 10% to 80% |
| POWER | |
| Power Supply | 100-240V~, 50/60Hz |
| Power Type | Built-In Power |
| Power Consumption | Typical: 309 W / Max: 318 W |
| CERTIFICATION | |
| Safety | CB / NRTL |
| EMC | FCC Class “A” / CE / KC |
| ErP / Energy Star | Yes (EU Only) / No |
| MEDIA PLAYER COMPATIBILITY | |
| OPS Type Compatible | No |
| SOFTWARE COMPATIBILITY | |
| Content Management Software | SuperSign CMS |
| Control and Monitoring Software | SuperSign Control+ / Control |
| Signage365Care | Yes |
| ACCESSORIES | |
| Basic Accessories | Remote Controller, Power Cord, QSG, IR Receiver, Regulation Book, Phone to RS232C Gender, FFC Cables (220mmx4ea for Connection between Panel and Signage Box), DP Cable, LAN Cable, RS232 Cable (4P-4P), LC Cable (VLC), Tapes, Screws, Shield Cover Assembly, Tiling Set Fixers, Flex Bars |
